FEIN 71230661000 AGSZ 18-90 LBL AS 18V Cordless Brushless Die Grinder Bare Unit
FEIN 71230661000 AGSZ 18-90 LBL AS cordless brushless die grinder (18V) – bare unit
The FEIN 71230661000 cordless die grinder is a compact 18V tool designed for controlled grinding and polishing work where access, manoeuvrability and clean running matter. Its brushless motor and dust-resistant design make it a practical choice for trade users who want consistent performance when working around aggressive mineral or ceramic dust.
Model AGSZ 18-90 LBL AS features electronic variable speed preselection to help match the tool to different abrasives and materials, along with protection features designed to support safe, dependable use on site or in the workshop.
Key Features
- Brushless FEIN PowerDrive motor: Built for long service life with efficient performance and reduced maintenance compared with brushed designs.
- Dust-resistant, closed motor housing: Helps protect the motor from aggressive ceramic and mineral dusts during grinding tasks.
- Electronic variable speed preselection: Infinitely adjustable speed control to suit a wide range of abrasive and polishing materials.
- Soft start: Supports controlled run-up for smoother handling at switch-on.
- Restart protection: Helps prevent the tool from starting unintentionally after a power interruption.
- Electronic overload protection: Designed to protect the tool under heavy load.
- Low-vibration design: Motor decoupling and additional vibration dampers help reduce vibration for more comfortable working.
- Innovative collets with all-round flange: Helps protect the workpiece and reduces the chance of the wrench slipping during tool changes.
Specifications at a glance
Suitable applications
- Grinding and polishing tasks where a compact die grinder and large plunge depth are beneficial.
- Work around mineral or ceramic dust where a dust-resistant motor housing helps protect the tool.
- Speed-sensitive finishing work where electronic speed preselection supports better control.
Comes with
- 1 x Die grinder
Technical specification table
| Brand | Fein |
|---|---|
| Part No. | 71230661000 |
| Tool type | Die grinder |
| Power source | Cordless |
| Voltage | 18 V |
| Battery type | Li-ion |
| Motor type | Brushless |
| No load speed | 2,900 – 9,000 rpm |
| Polishing disc diameter | 80 mm |
| Max grinding wheel diameter | 50 mm |
| Max collet capacity | 8 mm |
| Max cutter diameter | 12 mm |
| Vibration value (3-way) | αh,SG (Ø 50 mm) 3.2 m/s² |
| Kit type | Bare unit |
- Guarantees very long life with the next generation of brushless FEIN PowerDrive motors. Totally closed motor housing protects the motor from aggressive ceramic and mineral dusts.
- Ideal for every application. Optimum speeds, matched to a large number of abrasive materials and other materials using the infinitely variable, electronic speed preselection.
- Powerful. 30 % more efficiency than comparable universal motors with a rated output of 1 100 W.
- COOLPACK 2.0 technology delivers a 135% longer battery life and therefore makes longer operating times possible.
- State-of-the-art cell technology and intelligent battery management deliver 87% more power than with conventional batteries.
- ProCORE Li-Ion battery with high-power cells, charge status indicator and “Electronic Cell Protection” (ECP). ECP protects against overload, overheating and total discharge.
- Very smooth running and low-vibration working thanks to motor being decoupled from the housing and mounted separately and four additional vibration dampers.
- Extensive user protection features include soft start, restart protection and electronic overload protection.
- Innovative collets with all-round flange to protect the workpiece and prevent the wrench sliding off during tool changes.
- Fatigue-free working thanks to narrow grip dimensions, compact design and a well-balanced low weight.
- Separate motor electronics with dust guard in handle area.
- Compatible with all 18 V AMPShare ProCORE batteries and chargers for even more power and flexibility. Also suitable for 18 V Bosch Professional cordless devices.
- Bright working area thanks to integrated LED light.
- Ideally equipped for every job. Mobile working with the XL-BOXX system.
- Long, narrow neck allows tool to plunge a long way into workpieces (e.g. grinding inside pipes).
- Removable rubber collar bearing cover.
FEIN shape the future – and have been doing so for more than 150 years. Renowned as the first to design and manufacture the first cordless power tool in 1895, FEIN are specialists in the field of power tools and are the perfect workmate for working trades professionals: especially for the metal worker. With a user-centred focus as well as a result-oriented state of mind, FEIN produce first-class products that have the correct application solution, whether drilling, screwing, core drilling, grinding, cutting or sawing.
