Bosch GRL 650 CHVG Professional Rotation Laser With 4 x 1.5 V LR6 Batteries (AA),4 x 1.5 V LR20 Batteries (D) & Carry Case | 0601061V70
Bosch GRL 650 CHVG Professional rotary laser level (green beam) with carry case – 0601061V70
Bosch 0601061V70 is a Professional rotary laser level designed for accurate levelling and grading work, with a green beam for strong visibility on site. Built for demanding environments, the GRL 650 CHVG supports both outdoor and indoor setup tasks where speed, durability and clear reference lines matter.
The GRL 650 CHVG Professional adds Bluetooth® connectivity for remote settings control via the Levelling Remote App, helping you stay focused on the job while keeping the instrument configured from a distance.
Key Features
- Green beam rotary projection: Designed to deliver higher visibility in different lighting conditions for easier line pickup.
- Bluetooth® connectivity: Allows settings overview and remote control using the Levelling Remote App for efficient site workflow.
- Jobsite-ready build: Sturdily built to handle rough site conditions, including tripod tip-over up to 2 m.
- IP68 protection: Rated for dust and water protection to suit bad weather and harsh working environments.
- Long working range with receiver: Up to 650 m (diameter) when used with a compatible laser receiver.
- Selectable rotation speeds: Choose between 150 / 300 / 600 min−1 to suit the task and conditions.
Specifications at a glance
Suitable applications
- Outdoor levelling and grading tasks on construction sites.
- Interior installation work such as walls, ceilings and HVAC alignment.
- Setups requiring remote control and quick adjustments from a distance via app connectivity.
Comes with
- 1 x Rotation Laser
- 4 x 1.5 V LR6 batteries (AA)
- 4 x 1.5 V LR20 batteries (D)
- 1 x Carry case
Technical specification table
| Product type | Rotary laser level |
|---|---|
| Model | GRL 650 CHVG Professional |
| Part number | 0601061V70 |
| Laser projection | 1 x 360° |
| Laser class | 2 |
| Laser diode | 500 – 540 nm, < 1 mW |
| Working range (without receiver) | 70 m (diameter) |
| Working range (with receiver) | 650 m (diameter) |
| Compatible laser receiver | LR 65 G |
| Accuracy | ± 3.0 mm at 30 m (vertical); ± 1.5 mm at 30 m (horizontal) |
| Self-levelling range | ± 8.5% (± 5°) |
| Rotation speed | 150 / 300 / 600 min−1 |
| Operating temperature | -10 to 50 °C |
| Storage temperature | -20 to 50 °C |
| Dust & splash protection | IP68 |
| Tripod thread | 2 x 5/8" |
| Power supply | 4 x D cell batteries; 18 V Li-Ion battery |
| Dimensions (L x W x H) | 590 x 440 x 255 mm |
| Weight | 4.3 kg |
| GTIN | 4059952593661 |
